Get $100 discount code on a laser machine from Pascal Liu, visit his website Need Glock/SIG/AR15/1911 TEMPLATES for stippling?? Buy Color files for lightburn ? Check your ezcad 3 activations - Data specs for JPT sources Do you need help ?? Join the groups below. One of the best groups on facebook regarding fiber/uv lasers. Pixel2pulse 3D UV group Bogong Machinery inspired Feeltek 3D Laser Fiber Laser The Next Level Big Scary Lasergroup Fiber Laser Tips		Buy Jigs

Fiber laser (none mopa and mopa) can mark on different materials as : Aluminium, Gold, Platinum, Silver, Titanium, Brass, Tungsten, Carbide, Nickel, Stainless steel, Crome, Copper, Synthetic leathers, Carbon fiber, Fiberglass, PLT, PS, ABS, PBT, Silicon, Stones, Marble, Colored Acrylics

These parameters are provided as a "general range" and therefore some user testing and experimentation is required. Individual materials and preference will determine the final combination of settings for each application.
Learn how the hatches and frequency cause different effects. Look at it like sandpaper. Smaller frequency
more aggressive. And power is how much pressure you put down and speed is the rate of sanding the surface.
Here is ezcad files that is important for you to mark on stainless steel, it will give you some information what your fiberlaser can do.
1. Power vs Speed Grid 2. Power vs Freq Grid 3. Frequency vs Hatch Grid

CUT settings = Use 0.2mm offset in design for cutting.
If you want to contribute to this site, please register and add your fiber laser settings to help others.

The Pulse [ns] settings are for MOPA (Master Oscillator Power Amplifier) fiber laser only.
Suggested Material Settings - Click on material name to show settings.

REMOVE COATING FROM TUMBLERS

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
30W Raycus	1	32	0	1000		20			0.03

WHITE ON TUMBLERS

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
Raycus 30W	1	32	0	1000		32		0	0.03	150x150mm

50W JPT ENGRAVE POWDER COATED TUMBLER

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
50W JPT	1	55		500	0	50			0.04			second hatch is cleanpass
50W JPT	2	35		2000	0	30			0.04			second hatch is cleanpass
