These parameters are provided as a "general range" and therefore some user testing and experimentation is required. Individual materials and preference will determine the final combination of settings for each application.
Learn how the hatches and frequency cause different effects. Look at it like sandpaper. Smaller frequency
more aggressive. And power is how much pressure you put down and speed is the rate of sanding the surface.
Here is ezcad files that is important for you to mark on stainless steel, it will give you some information what your fiberlaser can do.
1. Power vs Speed Grid 2. Power vs Freq Grid 3. Frequency vs Hatch Grid

Do you need help ?? Join the groups below. I think these are one of the best groups on facebook regarding fiber lasers.

3D UV group

Fiber Laser The Next Level

Big Scary Lasergroup

Fiber Laser Tips & Trics

Laser Club

CUT settings = Use 0.2mm offset in design for cutting.
If you want to contribute to this site, please register and add your fiber laser settings to help others.

The Pulse [ns] settings are for MOPA (Master Oscillator Power Amplifier) fiber laser only.
Suggested Material Settings - Click on material name to show settings.

WHITE COLOR ON BRASS

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
Raycus 30W	1	100	90	2000		60		4	0.03
Raycus 30W	2	100	180	2000		60		4	0.03

DEEP ENGRAVE ON BRASS

Model	Hatch	Power %	Angle	Speed (mm/s)	Freq	Loop	Line Space
Raycus 30W	1	100	90	1500	35	25	0.02
	2	100	180	1500	35	25	0.02
	3	100	315	2000	75	5	0.02

CUTTING BRASS

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
Tykma 50 watt	1	100	45	1500		50		99	0.05	100mm s		Use Wobble 1mm and 0.05

BRASS COINS

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
Raycus 30W	1	50	0	200		20		0	0.01	150x150mm		All calc

0.4MM CUTTING BRASS WITH WOBBLE NO HATCH - OUTLINE ONLY

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
Raycus 30W	1	100		50	0	20		13				wobble Diameter 0.05. Distance 0.03

CUTTING BRASS 1.5MM

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
20 W raycus	1	100		300	0	20		300		70

CUT BRASS 0.5MM

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
JPT 50w	1	90		70	0	50						Wobble Diameter/Distance 0.01mm

BLACK ON BRASS

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
30W Raycus	1	90	90	150	0	20			0.02

BLACK ON BRASS JPT 50W

Model	Hatch	Power %	Angle	Speed (mm/s)	Pulse [ns]	Freq	Type	Loop	Line Space	Lens Type	Picture	Notes
JPT 50w	1	60	90	300	200	60			0.004	110
